Machined Bushings C93200 Rg7 Tin Bronze Bronze Gleitlager Raw Material

Name: Machined Bushings C93200 Rg7 Tin Bronze Bronze Gleitlager Raw Material
Brand: viiplus Bearing raw material
Price: 1 USD

China Machined Bushings C93200 Rg7 Tin Bronze Bronze Gleitlager Raw Material wholesale

Brand Name : viiplus Bearing raw material

Model Number : C93200(RG7) Lead tin bronze

Certification : ASTM B 505/B505M

Place of Origin : gleitlagerbuchsen china

MOQ : A minimum of/25kg

Price : discuss

Payment Terms : T/T

Supply Ability : bronze sleeve bushings, China, manufacturers, suppliers, factory, wholesale, Metallic Self Lubricating Bushings, Cast Iron Bearing, Sleeve Bushing, POM Bearing, Cast Iron Plain Bearing, Lubrication Bronze Bushing

Delivery Time : 5-25 works day

Packaging Details : Wooden play box

Material : C93200 RG7

choose shape : Billet/billet, hexagonal, sheet

features : High lead and high abrasion resistance

Item : CuSn7Zn4Pb7 bronze bushing

Get A Better Quote : tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer : https://www.viiplus.com/

High Light : Slit Oilless Bronze Bushing, Anti Fatigue Oilless Bronze Bushing, Maintenance Free Oilless Bronze Bushing

Gleitalger : A plain bearing, or more commonly sliding contact bearing and slide bearing, is the simplest type of bearing, comprising just a bearing surface and no rolling elements. Therefore, the journal slides over the bearing surface. The simplest example of a plain

Bush Bearings Manufacturers Suppliers Exporters : plain bearings. Long, maintenance-free service, manufactures bushings in various designs and from different materials. tiffany@viiplus.com, Bushings - Configure and purchase - https://www.viiplus.com/

Contact Now

Machined Bushings made from C93200 (RG7) Tin Bronze are commonly used as Gleitlager (sliding bearing) raw material due to their exceptional properties. This alloy, which is also known as SAE660 RG7, is a lead-tin bronze that is widely recognized as a "standard" bearing material.

C93200 RG7 Tin Bronze exhibits high strength and hardness, making it suitable for applications that require bearing bushings to withstand heavy loads and complex stress conditions. It also demonstrates excellent corrosion resistance, able to maintain its integrity in various acidic, alkaline, and saline environments.

The machining process allows for precise shaping and finishing of the bushings, ensuring a smooth and consistent surface for optimal sliding performance. The alloy's good casting and processing properties further contribute to the manufacturing of bushings with superior mechanical properties.

In summary, C93200 RG7 Tin Bronze is an excellent choice as Gleitlager raw material for machined bushings, offering high strength, hardness, corrosion resistance, and superior machinability.

C93200(RG7)Bearing raw material supply,Tin bronze raw materials can be used in auto parts, bearings and other fields

Composition (standard values) Sn 7 % Pb 7 % Zn 4 % Cu balance

RG7(C86300) bearing raw materials, lead tin bronze raw materials

Continuously cast OD up to 200 mm

CuSn7Zn4Pb7(GB/T 1176-1987)= G-CuSn 7 ZnPb(DIN)=C93200(SAE660 RG7)Chemical composition quality/%
Cu	Sn	Al	Fe	Mn	Ni	Pb	Si	P	Zn
81.0-85.0	6.3-7.5	0.01	0.2	-	1	6.0-8.0	0.01	1.5	2.0-4.0

Note: The raw material contains lead, which has a high content and is likely to pollute the environment. Please use it according to the actual situation

RG7(C86300) bearing raw materials, lead tin bronze raw materials Mechanical Properties

Tensile Strength,		Yield Strength, at 0.5% Extension Under Load,		Elongation, in 2 in. or 50 mm min	Brinell Hardness (500 kg load)	Remarks
ksi	MPa	ksi	MPa	%	typical BHN
35	241	20	138	10	65

RG7(C86300) raw materials Physical Properties

	USA Customary	Metric
material Melting Point - Liquidus	1730 °F	976 °C
material Melting Point - Solidus	1570 °F	854 °C
Density	0.322 lb/in3 at 68 °F	8.91 gm/cm3 at 20 °C
Specific Gravity	8.91	8.91
Electrical Conductivity	12% IACS at 68 °F	0.07 MegaSiemens/cm at 20 °C
Thermal Conductivity	33.6 Btu/sq ft/ft hr/°F at 68 °F	58.2 W/m at 20 °C
Coefficient of Thermal Expansion 68-212	10 · 10-6 per °F (68-212 °F)	17.3 · 10-6 per °C (20-100 °C)
Specific Heat Capacity	0.09 Btu/lb/°F at 68 °F	377.1 J/kg at 20 °C
Modulus of Elasticity in Tension	14500 ksi	100000 MPa

RG7(C86300) raw materials Bearing raw material application field

Hydraulic

Used in the manufacture of hydraulic valves, stem, gear pumps, vane pumps, piston pumps, oil cylinders and so on
The Car

Automobile: Turbocharger, engine, automobile air conditioning compressor, vehicle bridge
Basic industries

Basic industry: bearing retainer, bearing bush, bolt, nut, washer, worm wheel
The shope

Ship: propeller, propeller cap, worm wheel, Marine copper flange, copper shaft rod, copper sleeve
Engineering machinery

Construction machinery: rock drilling nuts, copper sleeve drill shank, wear-resistant sleeve moving parts
The railway

Railway: conductor bar, line guide, brake valve

RG7(C86300) raw materials Product size selection

Product description: lead tin bronze

Pipe :25.4 to 406.4mm outside diameter

Rectangle: Maximum 508mm

Standard length :381mm

Shape/form: semi-finished product, coarse or nearly clean, anode, bar, billet/flower, square, hexagonal, plate, profile or

Structural type, flat/elongated
